pro+ Surface Instruction for Use (209196 REV 8) 49
VERSACARE Bed—pro+ Surface Installation Instructions
(Warnings continued) To help prevent injury and/or equipment
damage, obey these warnings:
• Warning—The surface weighs
approximately 50 lb (22.7 kg). Lift and
move the surface with the handles. Do
not twist, and seek assistance when
necessary.
10. Use the surface handles on the side of the
surface to lift and install the surface on the
bed. Make sure the logo side is up and at
the foot end of the bed.
11. Put the bed in this configuration:
• Knee in the highest position
• Head in the highest position
• Bed in the highest position
Step 2: Route the Surface Power Cord (P3255A03 and
P3255A04)
Warning—Failure to route the surface power cord correctly could
cause a tripping hazard and/or the cord to be pinched during bed
functions. Injury and/or equipment damage could occur.
The surface power cord is
routed along the patient-left
side of the VersaCare Bed.
