pro+ Surface Instruction for Use (209196 REV 8) 51
VERSACARE Bed—pro+ Surface Installation Instructions
12. Route the power cord between the
head and seat sections on the left-
side of the bed.
13. Attach the first cord magnet to the
upper frame on the inside of the
intermediate frame, between the
siderail center arm and right
siderail weldment.
14. After attaching the first magnet,
route the cord over the siderail
center arm and pull through to the
front of the intermediate frame.
Make sure the power cord is routed
over the top of the siderail cross tube.
To Next Page
