Chapter 8 Appendix
Mini-Switch LB 471
77
Code
no.
Designation
Value range
Factory
setting
Device
setting
Page
40
Interference radiation detection
0 - 1
0
38
41
Waiting time after interference radiation
0 - 999
20
39
42
Signaling interference radiation
0 - 2
0
39
43
Signaling unlocked
0 - 2
0
39
44
Signaling minor errors
0 - 2
0
40
45
Signaling excess temp. detector (only FSK
1
)
0 - 2
0
40
46
Temperature threshold detector
(only FSK
1
)
0 - 99
40
40
47
Signaling excess temp. EVU
6
0 - 2
0
41
48
Temperature threshold EVU
2
0 - 99
50
41
50
Limit switch software
1.00 - 9.99
Version
41
51
Detector software (only FSK
1
)
1.00 - 9.99
Reading
41
52
Detector temperature °C (only FSK
1
)
-40 - 80
Reading
41
53
Detector high voltage (only FSK
1
)
500 - 1300
-1
42
54
detector HV start value (only FSK
1
)
500 - 1300
HV default
42
55
Source replacement
00.00 - 99.12
-1
43
56
Evaluation unit electronics temperature
-100 - 200
Reading
43
60
Test pulse generator
0 - 999.9
0
43
61
Test error relay
0 - 2
0
44
62
Test alarm relay
0 - 2
0
44
63
Test warning relay
0 - 2
0
44
64
Test display
44
65
Test keyboard
44
66
Status digital in
00.00 - 01.01
Reading
45
67
HV max for plateau measurement
500 - 1300
1000
45
68
Detector plateau measurement
(only FSK
1
)
0 - 5
0
46
70
Error log
0 - 1
0
47
71
Revision log
0 - 1
0
48
72
Save & Load / Reset
0 - 99
0
49
1
FSK = Detector with scintillator and FSK communication
6
EVU = Evaluation unit
