LIST OF SPARES PARTS
Code Representation Description
AC16589 Manifold
AC16590 Reagent piston stop
AC16591 Sample piston stop
AC16592 Pump motor+spindle
AC16593 Sample ceramic piston
AC16594 Reagent ceramic piston
AC16595 Wash station suction tip
AC16596 Wash station suction tip+dryer
AC16597 Wash station tip spring
AC16598 Vertical movement belt
AC16599 Polar movement belt
AC16600 Arm motor
AC16601 Contintuous current stirrer motor
AC16602 Stirrer paddle
Service Manual
118
