50
Test point Function
TP7 Decoder 2
TP8 Decoder 3
TP9 Decoder 4
TP10 Activation of LED 1
TP11 Activation of LED 2
TP12 Activation of LED 3
TP13 Activation of LED 4
TP14 Activation of LED 5
TP15 Activation of LED 6
TP16 Activation of LED 7
TP17 Activation of LED 8
TP18 Activation of LED 9
TP19 Activation of LED 10
TP20 Activation of LED 11
TP21 Activation of LED 12
LEDs Function (on condition)
LD1 340 nm LED
LD2 560 nm LED
LD3 670 nm LED
LD4 600 nm LED
LD5 535 nm LED
LD6 505 nm LED
LD7 635 nm LED
LD8 405 nm LED
LD9 Free position
LD10 Free position
LD11 Free position
LD12 I2C decoder indicator
4.7. Rotor boards - CIIM00052
e analyser has two CIIM00052 boards which are located in the sample and reagent rotor assemblies. Boath boards
have the same PCB but the fridge components have not been mounted on the sample rotor board. Each board has
a dierent board selection switch code.
Elements that are common to both boards
• Micro controller (U5)
• Cover sensor (U3)
• Control of fans located in the structure (U3 and U6)
