biosystems BA 400 - Minimum Maximum; AIII. Adjustment Margin Tables

AIII. Adjustment margin tables
Adjustment margins:
Parameter Minimum Maximum
Reading reference position - Well 1 7860 7905
Washing solution tare 0 -5 5
Washing solution tare 50 40 60
Washing solution tare 100 95 105
Washing solution tare 150 100 150
Waste tare 0 -5 5
Waste tare 50 40 60
Waste tare 100 95 105
Waste tare 150 100 150
ermal adjustment of reaction rotor 37,0 39,0
ermal adjustment of wash station 44,0 50,0
ermal adjustment of reagent tip 1 50,0 55,0
ermal adjustment of reagent tip 2 50,0 55,0
ermal test on reaction rotor 36.8 37,2
ermal test on wash station 45,0 50,0
ermal test on reagent tip 1 30,0 35,0
ermal test on reagent tip 2 30,0 35,0
Led 1 intensity reference value 6000 25000
Led 2 intensity reference value 14000 30000
Led 3 intensity reference value 12000 30000
Led 4 intensity reference value 4000 30000
Led 5 intensity reference value 3000 15000
Led 6 intensity reference value 6000 25000
Led 7 intensity reference value 6000 20000
Led 8 intensity reference value 4000 15000
Photometry margins:
Parameter Minimum Maximum
Dark current 3300 4500
Number of counts of main photodiode Minimum Maximum
Wavelength 340 600000 950000
Wavelength 405 850000 950000
Wavelength 505 850000 950000
Wavelength 535 850000 950000
