biosystems BA 400 - Page 56

56
Connector Function Pin
CN6 Distilled water bottle level detection sensor Pin 1: GND
Pin 2: Bottom sensor
Pin 3: GND
Pin 4: Top sensor
CN7 High contamination waste bottle scales signal Pin 1: GND
Pin 2: Signal 1
Pin 3: Signal 2
Pin 4: 3.3 V
CN8 Wash station scales signal Pin 1: GND
Pin 2: Signal 1
Pin 3: Signal 2
Pin 4: 3.3 V
CN9 B4 pump Pin 1: 24 V
Pin 2: Activation signal
CN10 B7 pump Pin 1: 24 V
Pin 2: Activation signal
CN11 B6 pump Pin 1: 24 V
Pin 2: Activation signal
CN12 B5 pump Pin 1: 24 V
Pin 2: Activation signal
CN13 GE1 wash station dispensation electro valve
assembly
Pin 1: 24 V
Pin 2: Activation signal
Pin 3: 24 V
Pin 4: Activation signal
Pin 5: 24 V
Pin 6: Activation signal
Pin 7: 24 V
Pin 8: Activation signal
Pin 9: 24 V
Pin 10: Activation signal
CN14 B10 pump Pin 1: 24 V
Pin 2: Activation signal
CN15 B9 pump Pin 1: 24 V
Pin 2: Activation signal
CN16 B8 pump Pin 1: 24 V
Pin 2: Activation signal
CN17 Wash station water thermostatting Pin 1: Output 1
Pin 2: Output 2
CN18 Wash station thermistor Pin 1: 3.3 V
Pin 2: sensor signal
CN19 B1 pump Pin 1: 24 V
Pin 2: Activation signal
CN20 B2 pump Pin 1: 24 V
Pin 2: Activation signal
CN21 B3 pump Pin 1: 24 V
Pin 2: Activation signal
