Connector Function Pin
CN8 Activation of electro valve EV3 Pin 1: 24 V
Pin 2: Activation signal
CN9 Activation of electro valve EV2 Pin 1: 24 V
Pin 2: Activation signal
CN10 Activation of pump GE1 Pin 1: 24 V
Pin 2: Activation signal
CN11 Activation of pump B3 Pin 1: 24 V
Pin 2: Activation signal
CN12 Activation of electro valve EV5 Pin 1: 24 V
Pin 2: Activation signal
CN13 Activation of electro valve GE3 Pin 1: 24 V
Pin 2: Activation signal
CN14 Activation of electro valve GE2 Pin 1: 24 V
Pin 2: Activation signal
CN15 Activation of electro valve EV6 Pin 1: 24 V
Pin 2: Activation signal
CN16 Reagent 2 dispensation motor Pin 1: Coil 1
Pin 2: Coil 1
Pin 3: Coil 2
Pin 4: Coil 2
CN17 Reagent 2 start-up detection Pin 1: Detection
Pin 2: GND
Pin 3: 5V
CN18 Reagent 1 dispensation motor Pin 1: Coil 1
Pin 2: Coil 1
Pin 3: Coil 2
Pin 4: Coil 2
CN19 Reagent 1 start-up detection Pin 1: Detection
Pin 2: GND
Pin 3: 5V
CN20 Sample dispensation motor Pin 1: Coil 1
Pin 2: Coil 1
Pin 3: Coil 2
Pin 4: Coil 2
CN21 Sample dispensation start-up detection Pin 1: Detection
Pin 2: GND
Pin 3: 5V
CN22 Manifold led Pin 1: 5 V
Pin 2: GND
