B-20 Computer Control
Each wavelength is represented by 'xxx,'. (3 ASCII digits followed by a comma).
Six wavelengths must be sent (24 bytes), followed by ETX after last comma.
If a wavelength is not to be specified, it must be replaced by '000'.
The Set Filter Table command returns the standard status response string.
After wavelength configuration, a self-test ('*' command) sequence must be run to
calibrate gains and generate self-check information for the new wavelength
configuration.
SPECTRAL SCANNING
The Spectral Scan ('&') command is defined as follows:
Host Limits Response
well (2) '00': scan entire strip
'01' - '08': scan well in
indicated row
strip (2) '01' - '12'
start wave (3) '200' - '800'
stop wave (3) '200' - '800'
wave step (3) '1' - '600'
series option (1) '0': single scan
‘1’:first scan in series
‘2’ : next scan
’3’ :last scan
