3-22 Operation
START MAPPING AT WELL LOCATION
The Start Mapping at Well Location screen (Figure 3-26) is only shown if
automatic mapping is selected. This option allows the user to enter the
location of the well that will be the starting point for automatic mapping.
Previously defined Starting Well Location appears on the top line of the
display.
S
T
A
R
T
M
A
P
P
I N
G
A
T
W
E
L
L
L
O
C
A
T
I O
N
?
A
0
1
Figure 3-26: The Starting Well Location screen
• Use the LEFT & RIGHT ARROW keys to move the cursor to the
previous or next editable field. The cursor will wrap around the edit
field.
• Use the NUMERIC & ALPHA keys to enter a letter or number at
the cursor location. For all prompts of a well location, only the
ALPHA keys are active for the first character and NUMERIC for the
second and third character.
BLANK MAP
This option (Figure 3-27) allows the user to select which blanking method to
apply to the assay. Any previously defined Blank Map value appears on the
top line of the display, with available options on the second.
The blanking options, AIR, FULL and CONSTANT, ROW and COLUMN,
and P-ACROSS and P-DOWN are displayed on three screens and are only
valid for automatic mapping methods.
