Page 22

2 Technical Features

Series Channel EQ Card High Pass Filter Reference

XB 1 JP1 — section 3.2.4

2 JP101 —

XV 1 JP1 — section 3.3.4

2 JP101 —

4X 1 JP2 JP3 section 3.6.4

2 JP9 JP10

3 JP2 JP3

4 JP9 JP10

4X DUAL 1 JP2 JP3 section 3.8.4

2 JP9 JP10

3 JP2 JP3

4 JP9 JP10

8X 1 JP5 JP3 section 3.10.4

2 JP7 JP14

3 JP6 JP4

4 JP8 JP12

5 JP5 JP3

6 JP7 JP14

7 JP6 JP4

8 JP8 JP12

Caution

Please make sure that the EQ card is installed correctly. Bittner Audio is not responsible for

damages resulting from improper installation of the EQ card.

2.15 Line Monitoring

In combination with a SXL II the ampliﬁers of the XR, 4X, 4Xi and 4Xe series may be used to monitor the

impedance of a loudspeaker line.

For more details please refer to section 3.14.9.3.
