3 Specifications of the Devices
3.12 8XT Series
3.12.1 General Information
Bittner Audio’s high quality transformers are not only available as single transformers, but come in an 8
channel chassis with only 2 RU.
Simply connect an 8X amplifier to an 8XT multichannel output transformer and you’ll be ready to meet our
European norms and standards.
3.12.2 Front & Rear View
Figure 3.35: 8XT Series - Front View
Figure 3.36: 8XT Series - Rear View
Connectors and Controls of the rear panel Reference
1 Amplifier Input
2 Loudspeaker Output
c
