3 Specifications of the Devices
Page 97
XR DSP 4X/4Xi/4Xe 4X DUAL 8X
Amplifier Functions
Standby Mode # x x x x
Mains Supply x x x x
Model x x x x
Firmware Revision x x x x
Delay Power On # x x x x
Online x x x x
Mode of Operation x x
Number of Channels x x x x
Alive x x x x
Channel Functions
Input Active* #
Input Inverted # x
Mute # x x x x
Gain # x x x x
Clip x x x x
Protect x x x x
Input Level x
Output Peak Voltage x x
Output Peak Current x x
Temperature x x
Monitor Output Bus A # x
Monitor Output Bus B* #
Monitor Output Inverted* #
Monitor Gain # x
Output Power x x
Output Load Impedance x x
Load Short x x
Load Open x x
Short Threshold # x x
Open Threshold # x x
Paging Input # x
Headroom x
Input Sensitivity # x
DSP # x
* These functions were used in former amplifier models
3.14.12 Error Codes
Because of the limited space of the LCD, abbreviations have to be used. Therefore error codes are made up
of:
• Device name (2 letters)
• Device number (2 figures)
• Parameters (3 letters)
The individual designations are separated by a point to increase readability. The parameter is abbreviated
with its first 3 letters.
The error codes are:
