A parameter may be changed by selecting it and pushing ENTER. The value will appear in brackets, e.g.
#Standby=[ON]. It may now be changed by using the UP and DOWN keys. If a large value range needs to
be changed (e.g. volume), holding the key down will speed it up. Push ENTER to finalize the setting, CANCEL
to abandon the changes.
User controllable parameters are indicated by a hash (#), e.g. #Standby=ON (refer to section 3.14.7.2).
Caution
If a connected amplifier is not featuring a certain parameter, the parameter will not be displayed.
3.14.7.2 Entry & Service Modes
In the first line’s right corner of the LCD, more information is displayed with 4 symbols.
Entry Mode
The entry mode defines how the parameters are displayed and edited. It may be selected by repeatedly
pushing the MODE key:
• <w1> only indicates the writable, respectively the controllable parameters (w = write). 1 means that
only the currently addressed amplifier/channel may be altered.
• <w2> is similar to w1 but will also set the parameters of the associated stereo channel. The menu
items are accordingly displayed, e.g. CHAN.3+4.
• <w*> is similar to w1 but the asterisk (*) represents all amplifiers/channels. In this mode, for example,
all amplifiers may be set to standby at the same time or set mute at the same time.
• <rw> is similar to w1 but additionally, all values, including the read only conditions are displayed, e.g.
ACStatus (= mains supply) of an amplifier, etc.
Service Mode
The two following Service Mode Levels are used to protect parameters from accidental changes.
• !sm1
Service Mode Level 1 - will be started by pushing the keys UP and DOWN at the same time. The
following parameters may then be changed:
– Network settings (refer to section 3.14.4.4)
– Delay time when a configurations is re-called via the logic inputs (refer to section 3.14.9.1)
– Continuous storage the SXL’s current condition to the intern flash disk ON/OFF (refer to sec-
tion 3.14.9.6)
• !sm2
Service Mode Level 2 – will be started by pushing the keys UP and DOWN at the same time, followed
by simultaneously pushing keys LEFT and RIGHT. The following parameters may then be changed:
– Toggle between manual and automatic confirmation of an error ON/OFF (refer to section 3.14.9.4)
3.14.7.3 Saving and Loading of Configurations
The saving and loading of a configuration on the SXL II requires two steps:
• Selection of configuration number
• Loading/Saving
