3 Specifications of the Devices
Page 41
3.6.3 Front & Rear View
Figure 3.17: 4X Series - Front View
Figure 3.18: 4X Series - Rear View
Connectors and Controls of the rear panel Reference
1 Fuse Mains Supply
2 Mains Power Switch section 2.1
3 Volume Controls section 2.5.3
4 Address-ID section 2.12
4 Noise Gate section 2.13
5 Loudspeaker Outputs section 2.8.1
6 Fan
7 Audio Inputs section 2.6.1
8 powerCON Connector
9 Alive Contacts section 2.10
9 Remote Power On/Off section 2.3.1
10 Status LED section 2.4.2
11 RS–485 Data Port section 2.11
