Page 44
3 Specifications of the Devices
3.7.3 Front & Rear View 4Xi
Figure 3.20: 4Xi Series - Front View
Figure 3.21: 4Xi Series - Rear View
Connectors and Controls of the rear panel Reference
1 Mains Power Switch section 2.1
2 Fuse Mains Supply
3 Audio Inputs Dante
TM
(optional) section 3.7.8
4 Volume Controls section 2.5.2
5 Fan
6 Loudspeaker Outputs section 2.8.1
7 powerCON Connector
8 RS–485 Data Port section 2.11
9 Alive Contacts section 2.10
9 Remote Power On/Off section 2.3.1
10 DIP Switches
Address-ID section 2.12
DANTE
TM
On/Off section 3.7.8
Clip Limiter section 3.7.7
Operation Mode section 2.9
11 Audio Inputs PHOENIX section 2.6.1
c
