3 Specifications of the Devices
• In case the error has been removed, the AMPLIFIER LINK STATUS LED will permanently light up again.
This safety feature is certainly not needed in every installation. Therefore, it may be deactivated. The
necessary parameter ClrErrorAuto in the menu SXLSTAT is only available after the activation of Service
Mode 2 (refer to section 3.14.7.2).
Caution
If the confirmation of errors is deactivated, the SXL II will no longer be compliant with safety
requirements. Therefore, it may be deactivated only in appropriate installations.
3.14.9.5 Backup Switching
The SXL II works seamlessly with the Bittner Audio Intelligent Backup Switch AX16. This device may be
connected to the SXL II via the system bus. Combined, the two devices offer a powerful solution for un-
interrupted operation.
In case of error of an amplifier, the SXL II is in direct control of the switching to the backup amplifier:
• The SXL II copies every setting of the defective amplifier to the backup amplifier
• The SXL II transmits the ID of the failed amplifier to the AX16
• The AX16 switches to the backup amplifier
This whole procedure will take only 250ms.
If the defective amplifier and the backup amplifier are not of the same model, the SXL II will copy as many
settings as possible. Different gain structures of the amplifiers are considered in advance and will – if possible
– be made up for.
The Force Amp Error function of the web interface (refer to section 3.14.8.7) offers a comfortable way to test
the combination of SXL II, AX16 and amplifiers, as well as their wiring. Every possible type of defect may be
tested.
Split Mode
Split Mode allows for the simultaneous operation of amplifiers with or without SXL II data port with an
AX16. Every combination or group is possible. Please note that that the amplifiers of a group (7+1, 3+1 or
1+1) have to be of the same type (i.e. low impedance or 100V).
Split Mode may be activated in the web interface of the SXL II on page AX16 (refer to section 3.14.8.7).
Please mind the followint points:
• Amplifiers without a dataport will be connected to the AX16 using the alive relay. The corresponding
DIP switch has to be set to the ON position (refer to section 3.13.5.2).
• Amplifiers with dataport have to be connected with the appropriate cable. The corresponding DIP
switch has to be set to the OFF position (refer to section 3.13.5.2).
• DIP switch 3 of the AX16 has to be set to the ON position (refer to section 3.13.5.4).
Caution
The 4X/8X cross cabling is not available in Split Mode.
