Page 24
3 Specifications of the Devices
3.1.3 Front & Rear View
Figure 3.1: BASIC Series - Front View
Connectors and Controls of the front panel Reference
Mains Power Switch section 2.1
Volume Controls section 2.5.1
Figure 3.2: BASIC Series - Rear View
Connectors and Controls of the rear panel Reference
1 Fuse Mains Supply
2 Loudspeaker Outputs Binding Post section 2.8.3
3 Loudspeaker Outputs SPEAKON section 2.8.2
4 Fan
5 Audio Inputs XLR/TSR section 2.6.2
6 Power Cord
7 Ground Lift section 2.7
8 Operation Mode section 2.9
c
2016 Bittner Audio Int. GmbH
