3 Specifications of the Devices
Page 87
Network Settings
Network Settings shows the active network parameters.
The Parameter Authorised IP is a subnet mask, which may be used to grant only a certain range of IP addresses
access to the SXL II.
Caution
Please contact your network administrator for the correct values of above parameters.
Syslog
The SXL II records every important event on its intern flash disk (refer to section 3.14.8.9). To obtain more
security, these record files may be mirrored via Syslog to any Host or IP address in the network and recorded
there.
This also applies to other SXL II within the network. It allows to display the logbooks of all SXL II on a
„Master SXL II“ by registering the IP address of the master.
Caution
Several free Syslog programs respectively deamons are available for Windows. Kiwi Enterprises,
for example, (http://www.kiwisyslog.com) is a well-known supplier.
Email/SMTP
SMTP stands for Simple Mail Transfer Protocol. The SXL II is able, via an appropriate gateway in the network,
to send logbook entries as emails.
To ensure trouble-free transmission of the data, the following parameters need to be set:
Function Description
Email from Sender’s address
Email to Recipient’s email address
SMTP Server Gateway Address
Caution
Please contact your network administrator for the correct values of above parameters.
User LED
The User LED may be utilized to signal any condition of the system. Using the control over Ethernet can be
used to manually switch the LED to identify a dedicated SXL II in a Rack.
The User LED may also indicate recording data on the internal flash disk (refer to Permanent Backup of
Operation Modes section 3.14.9.6).
Re-start
The SXL II may be re-started from the web interface. This feature is very useful after upgrading the firmware
via the network (refer to section 3.14.10.2).
To re-start, set the checkmark and click Set.
c
2016 Bittner Audio Int. GmbH
