VC-6000
TM
Compact monitor Part B BASE Module
- 8 - C100584.002 Module Vers. 08 © VC-6000
TM
Compact monitor Nov. 2014
1.3.2 Socket position and assigned connection plug
Module
socket
no.
Assigned
connection
plug
Suitable
for
Sensor
Interface
Module
Suitable
for BCU-
CON
Suitable
for
DC-OUT
Module
Suitable
for
RELAY-
OUT
Module
Suitable
for
BINARY-
IN Module
1 X1 Yes (Yes) (Yes) (Yes) (Yes)
2 X2 Yes Yes (Yes) (Yes) (Yes)
3 X3 Yes (Yes) (Yes) (Yes) (Yes)
4 X4 No No
Yes
Yes
Yes
5 X5 No No
Yes
Yes
Yes
6 X6 No No
Yes
Yes
Yes
7 X7 No No
Yes
Yes
Yes
8 X8 No
No
Yes
Yes
Yes
9 X9 No
No
Yes
Yes
Yes
The connection plan for a
VIBROCONTROL 6000 Compact monitor is exclusively
determined through the hardware equipment in the module socket positions.
E.g. Socket position no. 1 contains a A-TIM-24 V → the terminal layout of
A-TIM-24 V is valid for plug X1, etc.
