VC-6000
TM
Compact monitor Part B BASE Module
- 10 - C100584.002 Module Vers. 08 © VC-6000
TM
Compact monitor Nov. 2014
V-TIM (8 Hz) & V-TIM (15 Hz): Connection layout for 1-channel
input module for VS-sensor
Connection
X1/X2/X3
V-TIM (8 Hz and 15 Hz)
Pin 1 does not use
Pin 2 does not use
Pin 3 COM IN signal in (common)
Pin 4 SIG IN signal in (signal)
Pin 5 does not use
Pin 6 does not use
D-TIM: Connection layout for 1-channel for input module for
displacement sensor (e.g. Sensors of the series SD-xxx, IN-xxx
and D-xxxx)
Connection
X1/X2/X3
D-TIM
Pin 1 0 V OUT does not use
Pin 2 -24 V OUT does not use
Pin 3 COM IN signal in (common)
Pin 4 SIG IN signal in (signal)
Pin 5 does not use
Pin 6 0 V OUT does not use
GP-TIM: Connection layout for 2-channel input module for
current/voltage
Connection
X1/X2/X3
GP-TIM
Pin 1 Volt In A IN Voltage channel A
Pin 2 Curr In A IN Current channel A
Pin 3 COM A IN Common channel A
Pin 4 Volt In B IN Voltage channel B
Pin 5 Curr In B IN Current channel B
Pin 6 COM B IN Common channel B
Note:
Either two current inputs or two voltage inputs can be used at a GP-TIM. A
mixture of these input signal types is not possible !
