VC-6000
TM
Compact monitor Part B 1-channel input module for vibration velocity sensors
- 26 - C100584.002 Module Vers. 08 © VC-6000
TM
Compact monitor Nov. 2014
LED Status Explanation
OVERLOAD LED
Red Off No over-range
Red Flashing at 2 Hz An over-range exists; not yet
confirmed through the dialogue
Red Flashing at 0,5 Hz Only with OK latching parameter:
No existing over-range; an earlier
over-range not yet confirmed
through the dialogue
Red On Continuous over-range exists;
has been confirmed through the
dialogue
OK-LED
Green Off Continuous OK fault exists; has
been confirmed through the
dialogue
Green Flashing at 2 Hz Sensor OK fault not yet
confirmed through the dialogue
Green Flashing at 0,5 Hz Only with the OK latching
parameter:
No OK fault currently exists; an
earlier OK fault not yet been
confirmed through the dialogue
Green On No sensor OK fault
