Upgrading The Computer
Upgrading the Hard Disk Drive/SSD 6 - 15
6
Removing the 2.5" (63.5mm) HDD from the Bracket.
5. Remove screws & and separate the bracket from the HDD .
6. Reverse the process to install a new hard disk.
Figure 6 - 13
2.5" Hard Disk
Assembly Brackets
& Screws
1
2
3
4
1
3
2
4
