Dimensions without attachment parts
Dimensions approx. [mm] approx. [inch]
RC 40 RC 40 HP RC 40 RC 40 HP
A 2696 106.1
B 1182 1182 46.5 46.5
C 500 500 19.7 19.7
D 800 800 31.5 31.5
E 192 192 7.6 7.6
F 468 468 18.4 18.4
G 500 500 19.7 19.7
H 1010 1010 39.8 39.8
I 1000 1000 39.4 39.4
J 250 250 9.8 9.8
K 274 274 10.8 10.8
L1 50 50 2.0 2.0
L2 100 100 3.9 3.9
L3 Ø 18 Ø 18 0.7 0.7
M 240 240 9.4 9.4
N 260 260 10.2 10.2
O 7 7 0.3 0.3
P □ 180 □ 180 □ 7.1 □ 7.1
P1 □ 150 □ 150 □ 5.9 □ 5.9
P2 Ø 14 Ø 14 Ø 0.6 Ø 0.6
Q 600 600 23.62 23.62
R 1000 1000 39.4 39.4
S 140 140 5.5 5.5
T 312 312 12.3 12.3
U 297 297 11.7 11.7
V 527 527 20.7 20.7
V1 475 475 18.7 18.7
V2 300 300 11.8 11.8
V3 Ø 18 Ø 18 Ø 0.7 Ø 0.7
W 183 183 7.2 7.2
X 217 217 8.5 8.5
Product Description
