Dimensions approx. [mm] approx. [inch]
Nominal
diameter: 150
RC 40 RC 40 HP RC 40 RC 40 HP
O 150 150 5.91 5.91
Ø P 150 150 5.91 5.91
Ø Q 14 14 0.55 0.55
R 180 180 7.09 7.09
S 444 444 17.48 17.48
T 260 260 10.24 10.24
Deviations in individual dimensions within acceptable tolerances
due to production cannot be ruled out. The pipe connectors deliv-
ered as an option are designed according to the dimensional
drawing created for the order.
Inlet (substrate)
The feed unit of the separator has two short, straight pipe connec-
tors with a 6'' square flange each, whereby the unused connector
is closed with a blind flange.
Outlet (liquid phase and thick matter)
The pipe casing is equipped with a 6'' square flange as standard.
Optionally, adapters for DIN flanges or other connections as well
as the corresponding connection variations can be supplied. The
counter bearing casing is equipped with an outlet for the thick
matter.
Mounting rails
The Bioselect has two mounting rails.
4 slotted holes for M16 screws (mounting at the frame) or corre-
sponding heavy-duty anchors (mounting at the bottom) are avail-
able for mounting.
Product Description
BA-RC40_EN, 17.01.2024 www.boerger.de / www.boerger.com 59
