Bosch FPA-5000 System Description

10 en | Product Description Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
Further information can be found in Section 4.9 Functional Modules.
The technical data can be found in Section 7.3 Housing and Accessories.
ENO 0000 B Fire Service
Interface Module
Connecting fire service equipment complying with
DIN 14675
FPE-5000-UGM Interface Module Connection to UGM 2020 systems
IOP 0008 A Input/Output OC
Module
Individual displays or flexible connection of various
electrical devices, with 8 independent digital inputs
and 8 open collector outputs
IOS 0020 A 20 mA
Communication
Module
With S20, RS232 and S1 interfaces
IOS 0232 A RS232
Communication
Module
Connection of two devices using two independent
serial interfaces, e.g. a Plena Voice Alarm System,
laptop or printer.
LSN 0300 A LSN improved
Module 300 mA
Connection of an LSN loop with up to 254 LSN
improved elements or 127 LSN classic elements at a
maximum line current of 300 mA
LSN 1500 A LSN improved
Module 1500 mA
Connection of an LSN loop with up to 254 LSN
improved elements at a maximum line current of
1500 mA or 127 LSN classic elements at a maximum
line current of 300 mA
NZM 0002 A Notification
Appliance Zone
Module
Allows connection of two conventional, monitored
notification appliance circuit lines
RMH 0002 A Relay Module Monitored connection of external elements with
feedback, with two changeover contact relays
suitable for switching mains voltage
RML 0008 A Relay Module For low voltage switching, with eight changeover
contact relays
Module Description Function
NOTICE!
The simple, straightforward Fire System Designer (FSD) planning software can be used to
plan fire alarm systems that conform to the relevant limits (e.g. in terms of cable length and
power supply).
NOTICE!
The Bosch planning software for fire alarm systems enables the system dimensions, the
energy requirements and the quantity and prices of the elements required to be estimated at
each different phase in the planning process.
The software is designed for planners and engineering offices that want to produce a
quotation for a fire alarm system.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
