Modular Fire Panel Product Description | en 9
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Functions
Due to its modular structure, the FPA-5000 Modular Fire Panel provides complete flexibility
and thus customized solutions for any application.
The configuration of the components is supported by our Fire Systems Designer (FSD) during
the planning phase. This provides information about the size and number of housings, the
modules and the energy balance calculation.
Depending on specific requirements, the planning involves choosing from the following
options:
– Housing type (frame and wall mounting)
– Selection of a basic housing
– Extension housing, optional
– Power supply housing, optional
– Installation kits (optional) for installation in 482.6 mm (19") racks
– Panel controller
– Selection from a range of language versions
– Panel rail
– Selection according to housing type and/or number of functional modules required
– Power supply
– Batteries
– Power supply units for additional power supply
– Power supply brackets
The power supply brackets on frame installation housings are preinstalled ex works;
for wall-mounted housings, power supply brackets can be selected as required.
– Thermal printer
– THP 2020 A Thermal Printer
The thermal printer is used to document operating procedures on the panel, as well
as alarm and fault messages (see Section 4.13 THP 2020 A Thermal Printer,
page 130). Plain text can also be printed. Programming is carried out via the pro-
gramming software FSP-5000-RPS.
– Additional accessories
–Front doors
– Cable sets for special applications (see Section 4.10 Cable Sets, page 127)
– Functional modules
Functional modules are independent, encapsulated units that can be inserted into any
slot on the panel. The power supply and the data traffic with the panel are therefore
provided automatically. The module is identified by the panel with no further settings and
operates in the default operating mode (plug and play).
Wiring to external components is performed using compact connector/screw terminals.
After a replacement, only the connectors need to be reinserted; there is no need for
extensive rewiring.
Module Description Function
ANI 0016 A Annunciator Module Indicating system statuses; with 16 red and 16
yellow freely programmable LEDs
BCM-0000-B Battery Controller
Module
Monitoring the power supply to the panel and the
battery charge level
CZM 0004 A 4 Zone Conventional
Module
Connecting existing conventional peripherals using
four monitored conventional lines
