Changing the Paper Roll
The paper roll in the printer is changed as follows (see also Figure 4.88, Page 133):
1. Open the locks and remove the housing front panel.
2. Push down the paper locking lever.
3. Pull out the paper roll unit.
4. Tear off the paper before the last printed message, then hold the paper roll on the
collecting spool and remove the securing disk by pulling it to the left. Remove the printed
paper roll from the collecting spool.
5. Lift out the empty paper roll, making sure that the support pin does not fall out.
6. Remove the empty paper roll and slide a new paper roll onto the support pin.
7. Push the support pin with the new paper roll back between the metal clips.
8. Guide the paper behind the metal pin A and up behind the paper pressure roller B.
9. Pull out the paper up to the paper roll unit and secure the paper with at least one of the
pins of the securing disk. Always slide the securing pins accurately along the guide slots
of the collecting spool.
10. Let the collecting spool fall back into its original position and lift up the paper locking
lever (see arrow).
11. Close the housing front panel and secure with the safety screws.
12. If necessary, tension the paper by pressing the paper feed button.
NOTICE!
Only use the thermal printer paper specified by the manufacturer
(Bosch product ID 4.998.110.290, pack of 5 rolls).
The paper roll can be changed without turning off the printer.
