Modular Fire Panel Product Description | en 15
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Mounting Frames
All mounting frames have integrated terminal blocks for the mains supply, integrated junction
boards, as well as permanently installed cable ducts to facilitate clear and tidy cable routing.
The mounting frames are available in three sizes:
– FBH 0000 A Mounting Frame Large
– FMH 0000 A Mounting Frame Medium
– FSH 0000 A Mounting Frame Small
The large mounting frame is also available in a design with a distributor rail complying with
EN 60715:
– FHS 0000 A Mounting frame large with distributor rail
The housings for frame installation require the following mounting frames for surface-
mounted version:
Notes:
– All mounting frames have an opening for routing cables that is sealed with an insert. Pre-
punched cable entries can be created from this insert.
– The FBH 0000 A and FHS 0000 A mounting frames are equipped with an earth bar ex
works.
– For the FMH 0000 A, the FPO-5000-EB Earth Bar can be ordered as an extension if
required.
– For continuous installation in combination, all mounting frames have T-shaped guide rails
on the base and T-shaped grooves on the top.
Mounting Plate
An HMP 0003 A Mounting plate can be mounted in large mounting frames FBH 0000 A and
FHS 0000 A; this mounting plate can be individually equipped. It contains fixing holes for a
distributor rail.
The USF 0000 A is fitted with a mounting plate ex works, which can be equipped as required.
It contains fixing holes for two distributor rails.
Housing type Mounting frames
CPH 0006 A FBH 0000 A / FHS 0000 A
MPH 0010 A FBH 0000 A / FHS 0000 A
EPH 0012 A FBH 0000 A / FHS 0000 A
PSF 0002 A FSH 0000 A
PMF 0004 A FMH 0000 A
USF 0000 A FSH 0000 A
