16 en | Product Description Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
Equipment Limits
The table below shows the maximum number of:
–Modules
– Panel rails (short PRS 0002 A, long: PRD 0004 A)
The table below shows the maximum number of:
– Panel controllers
– UPS power supply units
– Batteries
Installation Kits for 482.6 mm (19") racks
Special installation kits are available for installing the frame installation housing in 482.6 mm
(19") racks:
No mounting frame is required when using the 482.6 mm installation kits.
Front Doors
The CPH 0006 A, MPH 0010 A and EPH 0012 A housings can be equipped with optional
transparent front doors made of impact-resistant plastic, with a lock on the left or right:
– FDT 0000 A Front Door Transparent, lock right side
– FDT 0003 A Front Door Transparent, lock left side
Housing type Modules PRS 0002 A PRD 0004 A
CPH 0006 A 6 1 1
MPH 0010 A 10 1 2
EPH 0012 A 12 - 3
PSF 0002 A - - -
PMF 0004 A - - -
USF 0000 A - - -
Housing type MPC UPS power
supply units
Batteries
CPH 0006 A 1 1 2 x 45 Ah
MPH 0010 A 1 - -
EPH 0012 A - - -
PSF 0002 A - 1 2 x 45 Ah
PMF 0004 A - 1 4 x 45 Ah
USF 0000 A - - -
Housing type Installation kit, 482.6 mm
CPH 0006 A FRB 0019 A
MPH 0010 A FRB 0019 A
EPH 0012 A FRB 0019 A
PSF 0002 A FRB 0019 A
PMF 0004 A FRM 0019 A
USF 0000 A FRS 0019 A

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
