Solution 6000-IP
Installation Manual Comms Programming
9-7
Bosch Security Systems 10/22 BLCC615I
Comms > IP Reporting >
Poll Rate
MENU 5-6-2
0 3 6 0
Seconds x 10
This menu allows the installer to program how often the
control panel sends a signal to the base station receiver
via Destination 1 and/or Destination 2. The poll interval
programmed in seconds and then multiplied by 10 (eg.
0009 = 90 sec's / 0360 = 1 hr / 4320 = 12 hrs and 8640 =
24 hrs). This should be set so that the control panel sends
a poll to the base station receiver at least once within the
polling time required.
1) Press [MENU] + [5] + [6] + [2]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
poll rate.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK] to select.
3) The keypad will display the current poll rate.
Poll Rate Rr1
0360 Seconds X 10
Press 0-9 OK to SAVE
4) Use the numeric keys [0] to [9] to program the new
poll rate in seconds (0000 to 9999 seconds x 10),
then press [OK] to save and exit or press [MENU] to
exit without saving.
Comms > IP Reporting >
ACK Wait Time
MENU 5-6-3
0 1 0
Seconds
This menu allows the installer to program the
acknowledge wait time in seconds for both Destination 1
and/or Destination 2. The acknowledge wait time can be
programmed between 1 and 255 seconds (0 = Disabled).
1) Press [MENU] + [5] + [6] + [3]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
acknowledge wait time.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK] to select.
3) The keypad will display the current acknowledge
wait time.
Ack Wait Time Rr1
010 Seconds
Press 0-9 OK to SAVE
4) Use the numeric keys [0] to [9] to program the new
acknowledge wait time in seconds (000 to 255),
then press [OK] to save and exit or press [MENU] to
exit without saving.
Comms > IP Reporting >
IP Format
MENU 5-6-4
00 - Conettix
0 1
01 - Conettix NNC (Anti Replay)
02 - CSV IP ALARM
03 - SIA UDP
04 - SIA
05 - Reserved
06 - CSV IP UDP
07 - Reserved
This menu allows the installer to program which IP format
the control panel will report to the base station receiver.
1) Press [MENU] + [5] + [6] + [4]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
acknowledge wait time.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK] to select.
3) The keypad will display the current IP format.
IP Format Rr1
01 - Conettix NNC
Press 0-9 OK to SAVE
4) Use the numeric keys [0] to [9] to program the new
IP format required, then press [OK] to save and exit
or press [MENU] to exit without saving.
To Next Page
