2-2 BBP™31 Sign & Label Printer User Guide
Unpacking and Setting up Printer
System Components
System Components
Figure 2-1. Printer Components
Note: The printer is equipped with a universal power supply and can be operated
with a supply voltage of 100 to 240 V~, 50- to 60 Hz. The printer senses the voltage
type and automatically adjusts for the power source.
1 Stylus 2 Display (with touchscreen)
3 Power Button 4 Enclosure Cover
5 Label Exit 6 Media Wiper
7 Media Guides 8 Media
9 Cutter 10 Ribbon Cartridge
11 Ribbon Cover 12 USB and Expansion Ports
13 Keyboard
2
1
4
5
10
6
8
12
11
9
3
7
13
