4-20 BBP™31 Sign & Label Printer User Guide
Working with Barcodes
Changing Barcode Options
Changing Barcode Options
Barcode options include changing the barcode symbology and data value, setting
a different ratio and density and increasing or decreasing the barcode size.
Barcode Size
To change the barcode size:
1. In the Editor, select a barcode object.
2. In the Control Panel
, select Size to increase or to decrease the
barcode vertically. Changes are immediately reflected in the
Editor .
Barcode Ratio
Ratio is the thickness between a narrow bar and a wide bar (overall width of the
barcode). Usually, the ratio is between 2:1 and 3:1. Does not apply to all
symbologies.
To change a barcode ratio:
1. In the Editor, select a barcode object. If the Barcode Content dialog box
opens, select Cancel.
2. In the Control Panel
, choose from one of the three options .
Changes are immediately reflected in the
Editor .
