3-4 BBP™31 Sign & Label Printer
User Guide
Set Label Attributes
Creating Auto-Sized Label
Set Label Attributes
Creating Fixed-Length Label
Use this procedure to create a label where the continuous-media label length is
set, not variable. Once selected, the printable area shown on the label is reduced
by the amount of the leader/trailer required for the installed supply, so that the total
label length output matches the selected length.
Note: The label size for die-cut media is already set and cannot be adjusted.
To create a fixed-length label:
1. From the Home page, select Menu .
2. In the menu list, select Size & Orientation .
Note: You can also access the Label Size & Orientation box by touching the
Label Size text at the bottom of the screen.
3. On the Label Size & Orientation dialog box, select Fixed Length .
4. In the Length field, enter the desired label length.
Note: Minimum supported length is 0.5 in. (12.7 mm). Maximum supported
length is 120 in. (3048 mm).
5. Select OK. The Status Bar indicates the new label length.
Creating Auto-Sized Label
Use this procedure to create a label where the continuous-media label length
adjusts to fit the data that you add to the label (variable label length).
Note: The label size for die-cut media is already set and cannot be adjusted.
To create an auto-sized label:
1. From the Home page, select Menu .
2. In the menu list, select Size & Orientation .
3. Select Autosize to Fit Data . When entering data, the label size
will automatically be adjusted to fit the data.
4. Select OK .
To Next Page
