Assembly
34/108 CLS Pro 600 – Line and Contrast Sensor
4. Screw the four threaded pins into the securing plates until the
control panel is held firmly in place.
5. Use the optional extension cable to connect the control panel
to the sensor.
6. Plug the extension cable connector into the sensor’s X100
socket.
