6
Operation
68/108 CLS Pro 600 – Line and Contrast Sensor
Parameter Function / Meaning
See also:
ekrPro Com60 with CLS Pro 600 Quick Ref-
erence Guide (MD.337.01.xx)
ekr 500 Plus with CLS Pro 600 Quick Refer-
ence Guide (MD.341.01.xx)
Please note:
The system loads the last activated mounting position
with each system restart.
6.7.1.5 \\configuration\edit menu configuration\
edit menu configuration:
The menu access rights and the quick menu position are defined
in this sub-menu.
See Sections 6.6.3 and 6.6.4 for more detailed descriptions.
6.7.2 Parameter
The parameters that apply to the measuring process are as-
sembled in this section of the main menu.
Meanings and procedures for the individual settings are described
below.
6.7.2.1 \\parameter\jobs\
jobs:
The job administration procedure is described in detail in Section
6.6.2.
6.7.2.2 \\parameter\illumination\
illumination:
The parameters that apply to the lighting are set up in this sub-
menu.
Parameter Function / Meaning
time [ms]:
Use this parameter to set up the CCD line il-
lumination time. This affects the control
measuring cycle time. If a value of > 2 ms is
selected, then no more details can be selec-
ted, e.g. slightly broken lines.
Setting Range: 2 – 64 ms
Default Setting: 2 ms
