BST CLS Pro 600 User Manual

6
Operation
70/108 CLS Pro 600 – Line and Contrast Sensor
Parameter Function / Meaning
Setting Range: 10 – 100
Default Setting: Automatic
A 10 setting is used to detect weak contrasts
and a 100 setting is used for detecting good
contrasts.
auto adjustment:
Switches the automatic determining of the
contrast detection search threshold on and
off.
Setting Options: ON / OFF
Pre-Adjustment: ON
min. line width:
This parameter is used to define the min-
imum width and it is needed to ensure that
the system detects a line as a line. Setting a
high value will prevent noise being generated
by high-contrast scratches, etc. A smaller
value can be set up if very small lines are de-
tected reliably.
Settings: 0.1, 0.2, 0.3, 0.4, 0.5 mm
Default Setting: 0.3 mm
6.7.2.5 \\parameter\contrast tracking\
contrast tracking:
The tracking conditions for exceptional materials are optimized in
this sub-menu, e.g. poor contrast or print edges with different col-
ors.
6.7.2.6 \\parameter\plausibility check\
plausibility check:
This sub-menu includes the parameter that will be used to check
the plausibility. This is described below.
Parameter Function / Meaning
edge color:
This parameter defines the type of color
checks to be used for edge scanning. The de-
tails of how the color will be checked always
refer to the screen display.
Setting Options:
all
off
only right side
only left side
Pre-Adjustment:
all
