Operation
6
CLS Pro 600 – Line and Contrast Sensor 75/108
Setting Options:
off
2 values
4 values
8 values
16 values
32 values
64 values
128 values
256 values
Pre-Adjustment:
off
Example:
The new measured value is determined as follows when using a
weighting of 64 values:
(Sum of the last 64 values – last value + new value) / 64
6.7.2.11 \\parameter\recapture factor\
recapture factor:
Use this parameter to define the step width that the system will
use for scanning the new edge / line position after the contrast
was lost.
The following benchmark value applies:
■ Small value – for broken lines
■ Big value – for a splice.
Setting Range: 0.001 – 10.000
Pre-Adjustment: 0.01
6.7.2.12 \\parameter\web stop detection\
web stop detection:
Use this parameter to switch the automatic web movement de-
tection on and off. If this function is switched on then web move-
ment will be checked if the edge was lost. The search area will be
only be opened if web movement has been detected or if an edge
cannot be found. We recommend that the default setting is never
changed.
Setting Options: ON, OFF
Pre-Adjustment: ON
6.7.3 Remote Control EKR
The remote control ekr sub-menu includes the gain factor Xp
parameter. This enables you to enter the controller’s remote gain
factor adjustment.
Setting Range: 0.00 – 999.99
