2007 Buell P3: Maintenance 1-41
HOME
CRITICAL FASTENER TORQUE VALUES 1.23
GENERAL
Check stabilizer links and engine mounts for damage and
hardware for proper tightness:
Inspect muffler strap and exhaust system hardware for dam-
age and proper tightness:
Inspect critical fasteners (listed below) for proper tightness as
recommended in 1.3 MAINTENANCE SCHEDULE.
TORQUE VALUES
ITEM TORQUE
Left handlebar control fasteners 25-33 in-lbs 2.8-3.7 Nm
Right handlebar control fasteners 25-33 in-lbs 2.8-3.7 Nm
Handlebar fasteners 120-144 in-lbs 14-16 Nm
Brake banjo bolts 16-20 ft-lbs 22-27 Nm
Front brake caliper mounting bolts 18-22 ft-lbs 24-30 Nm
Rear (large) brake caliper mounting bolt 18-22 ft-lbs 24-30 Nm
Rear (small) brake caliper mounting bolt 14.5-18 ft-lbs 20-24 Nm
Brake caliper pin 132-174 in-lbs 15-20 Nm
Front rotor TORX screws 24-27 ft-lbs 33-37 Nm
Rear rotor TORX screws 24-27 ft-lbs 33-37 Nm
Front axle nut 38-42 ft-lbs 52-57 Nm
Rear axle nut 49-51 ft-lbs 67-69 Nm
Front fork upper triple clamp pinch bolts (at sliders) 13-16 ft-lbs 18-22 Nm
Front fork upper triple clamp pinch bolts (at center cap) 84-120 in-lbs 10-14 Nm
Front fork lower triple clamp pinch bolts 22-29 ft-lbs 30-39 Nm
Muffler fasteners (front and rear) 17-19 ft-lbs 24-25 Nm
Tie bar (all) 30-33 ft-lbs 41-45 Nm
Front isolator mounting bolt 63-70 ft-lbs 86-95 Nm
Frame to rear isolator fastener 30-33 ft-lbs 41-45 Nm
