2007 Buell P3: Drive/Transmission 6-17
HOME
TRANSMISSION 6.5
GENERAL
See Figure 6-23. The transmission is a five-speed constant-
mesh type housed in an extension of the crankcase.
Figure 6-23. Transmission Power Flow
413 25 413 25
41325
413 25 413 25
41325
Neutral
– Power flow
– Sliding member
Countershaft
Mainshaft
Out
1st Gear
Mainshaft
3rd Gear
Countershaft
Mainshaft
Out
2nd Gear
Countershaft
Mainshaft
In
In
4th Gear
Countershaft
Mainshaft
In Out
5th Gear
Countershaft
Mainshaft
Out In
b1068x6x
Countershaft In
