2007 Buell P3: Electrical 7-1
HOME
SPECIFICATIONS 7.1
Table 7-1. Battery Specifications
Rating 12 VDC/12AH/200CCA
Type Sealed
Table 7-2. Alternator Specifications
AC Voltage Output 19-26 VAC per 1000 engine
RPM
Stator Coil Resistance 0.2-0.4 Ohms
Table 7-3. Regulator Specifications
Voltage Output @ 75°F 14.3-14.7 VDC
Amperes @ 3600 RPM 22 Amps
Table 7-4. Spark Plug Specifications
Spark Plug 10R12A
Size 12 mm
Gap 0.035 in. 0.9 mm
Torque 11-18 ft-lbs 14.9-24.4 Nm
Table 7-5. Ignition Coil Resistance
Primary Winding 0.4-0.6 ohms
Secondary Winding 7,720-9,440 ohms
Table 7-6. Spark Plug Cable Resistance
Spark Plug Cable 2,375-5,833 ohms
Table 7-7. Ignition Timing Spark
Occurrence
RPM
TP SENSOR
LOW VOLTAGE
(PT)
HIGH VOLTAGE
(WOT)
1200 RPM (Idle) 20˚ BTDC 18˚ BTDC
3000 RPM 30˚ BTDC 18˚ BTDC
6000 RPM 45˚ BTDC 35˚ BTDC
Curve Switch Point TP Sensor Input 2.4V
Rev Limit 6500 RPM
Table 7-8. Electrical Specifications
ELECTRICAL SYSTEM AMPERES
Main Circuit Breaker 30
Ignition Fuse 7.5
Light Fuse 15
Accessory Fuse 7.5
System Fuse 15
Key Switch Fuse 15
Table 7-9. Bulb Specifications
LAMP DESCRIPTION
BULBS
REQUIRED
WATTS AMPS
PART
NUMBER
Headlamp High/Low 1 60/55 4.68/3.12 67713-86
Marker Lamps Tail/Stop Lamp 1 5/21 0.42/1.75 68169-90A
Turn Signal Lamp, Front and Rear
(1 bulb each)
4 10 0.74 Y0042.K
Indicator Lamps
(in speedometer)
High Beam Indicator, Turn Signal Indicator Non-replaceable LEDs
Oil Pressure Indicator, Neutral Indicator
