2007 Buell P3: Electric Starter 5-1
HOME
SPECIFICATIONS 5.1
TORQUE VALUES
Table 5-1. Starter Specifications
ELECTRICAL INFORMATION
Free Speed 3000 RPM (min.) @ 11.5 V
Free Current 90 Amp (max.) @ 11.5 V
Stall Current 400 Amp (max.) @ 2.4 V
Stall Torque 8.1 ft-lbs (11.0 Nm) (min.) @ 2.4 V
Table 5-2. Service Wear Limits
STARTER COMPONENTS IN. MM
Brush Length minimum 0.433 11.0
Commutator Diameter minimum 1.141 28.981
ITEM TORQUE NOTES
Battery terminal bolts 72-96 in-lbs 8-11 Nm Page 5-19
Starter battery positive cable nut 80-100 in-lbs 9-11 Nm Metric, Page 5-19
Starter mounting bolts 13-20 ft-lbs 18-27 Nm Page 5-19
