2007 Buell P3: Chassis 2-67
HOME
REMOVAL - REAL FRAME
ASSEMBLY
1. Remove tail section.
2. Disconnect rear wire harness connector [7] (6-place
amp), located under seat near fuse block. Detach con-
nector from “T” stud.
3. See Figure 2-110. Remove fasteners (13) and bracket
(12).
4. Remove fasteners (11).
5. Slide rear frame assembly (10) out.
INSTALLATION - REAR FRAME
ASSEMBLY
1. See Figure 2-110. Slide rear frame assembly (10) into
frame.
2. Install fasteners (11).
3. Install brackets (12) and fasteners (13).
4. Connect rear wire harness and mount on “T” stud.
INSTALLATION - TAIL SECTION
1. See Figure 2-110. Install license plate bracket (5) using
fasteners (4) and nuts (9) in rear holes.
2. Install taillight using flat washers and nuts.
3. Install turn signals (6) using lock washers (7) and nuts
(8).
4. Connect turn signal wires and taillight wires. Cable tie
together.
5. Install tail section (1) using fasteners (3, 19, 20).
6. Connect battery negative cable.
11WARNING1WARNING
After installing seat, pull upward on front of seat to be
sure it is in locked position. While riding, a loose seat can
shift causing loss of control, which could result in death
or serious injury. (00070a)
7. Install seat. See 2.28 SEAT.
