Figure 7-8. Continuous or No Spark At Spark Plug
3.0-3.5 VDC
YES
Measure Voltage On Connector [134B] Between Socket C, (GY), And Socket B, (BK).
Is Voltage 11-13 VDC?
NO
Is Bank Angle Sensor
Correctly Installed?
Repair Open In (GY) Wire Between Bank Angle
Sensor And Ignition Fuse.
Are Ferrous Metals Located Within 0.250 in. (6.4 mm)
Of Sides, Face, Or Top Of Bank Angle Sensor?
YES
NO
Install Properly.
Return To Original
Configuration.
NO
Replace Bank Angle Sensor.
YES
5007
5013
