Canon imagePROGRAF iPF610 User Manual

Contents
Contents �x
Clean�ng the Pr�nter ......................................................................................642
Clean�ng the Pr�nter Exter�or ...................................................................................................642
Clean�ng Ins�de the Top Cover ................................................................................................644
Clean�ng the Paper Reta�ner ...................................................................................................647
Clean�ng the P�ck Up Roller ....................................................................................................648
Clean�ng the Pr�nthead ............................................................................................................649
Other Ma�ntenance .......................................................................................650
Prepar�ng to Transfer the Pr�nter .............................................................................................650
Updat�ng the F�rmware ............................................................................................................655
Troubleshooting 656
Frequently Asked Quest�ons .........................................................................656
Frequently Asked Quest�ons ...................................................................................................656
Spec�fy�ng Paper �n the Pr�nter Dr�ver .....................................................................................658
Pr�nt�ng does not start ...................................................................................659
The Data lamp on the Control Panel does not l�ght up ............................................................659
The Pr�nter Does Not Respond Even �f Pr�nt Jobs are Sent ....................................................659
The Display Screen indicates the system is lling with ink ......................................................659
Cannot pr�nt over a network ..........................................................................660
Cannot connect the pr�nter to the network ..............................................................................660
Conguring the Communication Mode Manually .....................................................................661
Cannot pr�nt over a TCP/IP network ........................................................................................662
Cannot pr�nt over AppleTalk or Bonjour networks ...................................................................662
Cannot pr�nt over a NetWare network .....................................................................................663
The pr�nter stops dur�ng a pr�nt job ...............................................................664
An error message �s shown on the D�splay Screen .................................................................664
The pr�nter ejects blank, unpr�nted paper ................................................................................664
Problems w�th the pr�nt�ng qual�ty .................................................................665
Pr�nt�ng �s fa�nt .........................................................................................................................665
Paper rubs aga�nst the Pr�nthead ............................................................................................666
The edges of the paper are d�rty .............................................................................................667
The surface of the paper �s d�rty ..............................................................................................668
The back s�de of the paper �s d�rty ..........................................................................................668
Band�ng �n d�fferent colors occurs ...........................................................................................668
The contrast becomes uneven dur�ng pr�nt�ng ........................................................................668
Colors �n pr�nted �mages are uneven .......................................................................................669
Problems w�th the pr�nt�ng qual�ty caused by the type of paper ..............................................670
L�nes are m�sal�gned ...............................................................................................................670
The length of pr�nted �mages �s �naccurate ..............................................................................670
Documents are pr�nted �n monochrome ..................................................................................670
Pr�nted colors are �naccurate ...................................................................................................671
Image Edges are Blurred or Wh�te Band�ng Occurs ...............................................................671
Documents are pr�nted crooked ..............................................................................................671
F�ne Scratches Appear on Glossy Paper from the Cassette ...................................................672
Roller marks are left across the tra�l�ng edge of paper ............................................................672
L�ne th�ckness �s not un�form (W�ndows) .................................................................................672

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
