Canon LBP7010C - Names and Dimensions of each Part

To Next Page

To Previous Page

019A-014

Part Name

Front View

(1) Output Tray (5) Multi-purpose Tray (9) Front Cover

(2) Ventilation Slot

(6) Control Panel (10) Power Switch

(3) Lift Handle

(7) Top Cover (11) Paper Guides

(4) Tray Cover

(8) Auxiliary Tray

Rear View

(1) Ventilation Slots (4) USB Connector (6) Ventilation Slot

(2) Rear Cover

(5) Power Socket (7) Lift Handle

Names and Dimensions of Each Part

㻠㻟㻌㻛㻌㻟㻠㻟
