3-CONTROLSANDINSTRUMENTS

Internalcablights

Cablights

Pressthemaplightbutton(1)toturnON/OFFtheright-

handcablight(2).

LEIL15WHL0544AB1

PressthedomelamptoturnON/OFFtheleft-handcab

light.

LEIL16WHL1330AB2

3-87
