7-MAINTENANCE

Machinettings-Grease

Greasethemachineattheremotelocationsevery50hours.Insevereconditions,suchasimmersioninwater,itmay

benecessarytoreducethegreasingserviceintervals.

Prioroperation:

Cleanaroundtheareatobegreasedbeforeservice.

Machinegreasettings

Servicespecications

GreaseSpecicationTUTELAMOLYGREASEGR-75

Driveshaftcarrierbearing

Tiltcylinder

Greasethedriveshaftcarrierbearingandthetiltcylin-

derattheremotegreaselocations(frontleft-handof

machine).

LEIL15WHL1835AA1

Rearaxletrunnion

Greasetheaxleoscillationattheremotegreaseloca-

tions(rearright-handofmachine).

LEIL15WHL1836AA2

7-45
