7-MAINTENANCE

Every250hours

Driveshaftslipjoints-Grease

Greasethedriveshaftslipjointsevery250hoursormoreoftenifconditionssorequire.

Prioroperation:

Alwayshavethemachineonrm,levelgroundwiththebucket/attachmentontheground.Makesureallresidual

pressureisrelievedfromthecircuitsbeforebeginningmaintenance.

NOTICE:insevereconditions,suchasimmersioninwater,itmaybenecessarytoreducethegreasingserviceinter-

vals.

Servicespecications

GreaseSpecicationTUTELAMOLYGREASEGR-75

1.Thegreasezerkislocatedonthedriveshaft.Parkthe

machinesothatthezerkisaccessible.

LEIL15WHL1835AA1

2.Cleanaroundtheareatobegreasedbeforeservice.

3.Greasethedriveshaftslipjoint.

7-65
