Case 621G - Multifunction Keypad

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

Multifunctionkeypad

LEIL16WHL1124FB1

NOTE:allmultifunctionkeypadbuttonsaremomentaryswitcheswithLEDindicatorofcurrentstatus.WhentheLED

isONthecorrespondingfunctionisactivated.

1.Parkingbrake

Presstheparkingbrakebuttontoengage/disengagetheparkingbrakeonthetransmissionoutput

shaft.

LEDcolor:red.

2.Beacon

PressthebeaconbuttontoturnON/OFFtherotatingbeacon.

LEDcolor:green.

3.Worklights1

Presstheworklight1buttontoturnON/OFFthefrontworklights.

LEDcolor:green.

4.Worklights2

Presstheworklight2buttontoturnON/OFFthefrontandrearlights.

LEDcolor:green.

3-24
